GE HEALTHCARE
DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
Section 3-4 - Completing the Installation 3-17
3-4-4 Video Specification
3-4-5 Software Option Configuration
3-4-5-1 Onsite check and configuration
Select Utility > Admin > System Admin and check the option software to be installed.
Table 3-9 Video Specifications
CRT LCD
Timing Parameter
800x600
75Hz
Timing Parameter
1280 x 1024
60Hz
Horizontal Rate [kHz] 46.88 Horizontal Rate [kHz] 64
Horizontal Period [µs] 21.33 Horizontal Period [µs] 15.625
Pixel Clock [MHz] 49.50 Pixel Clock [MHz] 108
H Blank Width [µs] 5.17 H Blank Width [µs] 3.778 (408dots)
H Sync Width [µs] 1.62 H Sync Width [µs] 1.037 (112dots)
H Front Porch [µs] 0.32 H Sync Front Porch [µs] 0.444 (48dots)
Active Horizontal Period [µs] 16.16 Active Horizontal Period [µs]
11.852
(1280dots)
Vertical Rate [Hz] 75.00 Vertical Rate [Hz] 60.0
Vertical Period [ms] 13.33 Vertical Period [ms]
16.67
(1066lines)
V Sync Width [lines=ms] 25=0.53 V Sync Front Porch [ms] 0.016 (1 line)
V Front Porch [lines=µs] 3=64.00 Equalization Porch None
Equalization Gate [lines=µs] 1=21.3 Lines: Field/Frame 1066
Lines: Field/Frame 625 Active Lines/Frame 1024
Active Lines/Frame 600
