GE LOGIQ 7 Service Manual

GE HEALTHCARE
DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
5-6 Section 5-2 - Hardware Compatibility Matrix
5-2-1-5 Backend
Figure 5-30 Backend - FRU Compatibility
R8.0.x R8.0.x R8.0.x R8.0.x
Latest Software
SW Upgraded BT09 (w BT02/BT03 console)
SW Upgraded BT09 from BT04/BT06/BT07
19 inch LCD Upgraded BT09 from 17 inch LCD
R8.0.X (BEP4)
comment
5119906-2
BCOMPSW3 SVC CSL L7
(w/o Video Card)
YYNN
No Video card mounted. Need to reuse Video Card
when BECOMP3 replace to this new one. Pentium 4
(BEP3) PCMother +CPU+PC2IPB+ATX
+Ethernet+HDD+Chasis +Memory+ MiscParts
5119906-3
BCOMPSW3 SVC CSL L7
(w/o Video Card / PC2IP)
YYYN
No Video card/PC2IP/FALCON mounted. Need to
reuse Video Card / PC2IP/FALCON when BECOMP3
replace to this new one. Pentium 4 (BEP3)
PCMother +CPU+ATX +Ethernet+HDD+Chasis
+Memory+ MiscParts +BaseImageCD
5119906-4
BCOMPSW3 SVC CSL L7
(w/o Video Card / PC2IP)
YYYN
No Video card/PC2IP/FALCON mounted. Need to
reuse Video Card / PC2IP/FALCON when BECOMP3
replace to this new one. Pentium 4 (BEP3)
PCMother +CPU+ATX +Ethernet+HDD+Chasis
+Memory+ MiscParts +BaseImageCD
5308149 SVP-BECOMP4-L7 N N N Y
No Video card/PC2IP/FALCON mounted. Need to
reuse Video Card / PC2IP/FALCON when BECOMP4
replace to this new one. Core2 DUO (BEP4)
PCMother +CPU+ATX +Ethernet+HDD+Chasis
+Memory+ MiscParts
5316350 SVP BECOMP4 PARTS N N N Y
Misc. parts for BEP4. Parts include SATA
signal/power cable for HDD, DVI-VGA connector,
BEP4 internal USB cables and BEP4 Label
2304809-2 P9536RH BATTERY PACK YYYY
5118511 Extended MEMORY3 LOGIQ7 YYYN Never be used on BEP2/BEP4
5306528 DDR2 MEMORY4 1GB NNNY
5118510 HD LOGIQ7 YYYN 80GB PATA
5306526 SATA HDD 160GB NNNY 160GB SATA type. To be used with BEP4
5179643 HDD For Consip L7 Console NNNN160GB PATA type
FC200656 PC2IP II B Y Y* N N
Only supported by BECOMPSW3
*Y if BT04/BT06 / N if BT06-2/V65x/BT07~
FC200755 PC2IP 3 NNYYP
C2IP3 need R620 application
2362887 P9536TK AGP BOARD ASSY Y Y+ N N
G550 Video Card AGP Type for CRT console
'+Y if CRT console
5111298 DUAL DVI AGP NY$Y N
SONO64 Video Card AGP Type : Only for LCD System
'Y$ if LCD console
5121039 PCI VGA NY$Y N G450 Video Card PCI Type : Only for LCD System
5306525 PCI Express Graphic board NNNY Matrox P690 Video Card for PCI-E slot
5142743 BECOMP3 Rear Fan Assy YYYYCommon for BEP3/BEP4
TBD SCSI Card Y NNN
Mounted only on Upgraded BT04
/BT06
system in
BECOMP3
for MOD Connection
5147460 F
ALCON
Capture Board NY%YY
VideoCapture Board directly from REAN3 on BT06-2
console
Y% if upgraded from BT06-2/V65x~ (with REAN3)
5169391 ? YC Cable (S-Video) NY%YY
Cable that connects VideoCapture Board between REAN3
on BT06-2 console
Y% if upgraded from BT06-2/V65x~ (with REAN3)
2384944 P9536CE DGPCIO/VIC_SVC NNNN
Only suppoted by BEP2. Even if BEP2 mounted, if PCVIC
is mounted, order PC2IO/VIC for BT01 console.
5133526 DGPCIO VIC 2-A ASSY YYYN Updated for LCD
2389075 ? PCI CABLE
YYYY
5301220-2 PCI-DGVIC2 Assembly
NNNY
5257226 BulkHead for L7 and LS6
NNNY
5257231 Cable13 for BulkHead
NNNY
5257233 Cable25 for BulkHead
NNNY
FRU Part# Description
FRU compatibility
BT09
～
