GE HEALTHCARE
DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
8-38 Section 8-2 - Software Loading Procedures for BT09 (R8.x.x or later)
8-2-10-4 Check LCD Monitor Hardware Setting
For 19 inch Monitor
To adjust the brightness:
1.) Press the Toggle button (2) or (3) Once for brightness adjustment.
a.) Verify that Brightness is 80 (Dark Room) or 100 (Bright Room).
If it is not, increase brightness to press the adjustment button (3).
If it is not, decrease brightness to press the adjustment button (2).
b.) Press the button (1) Once. The brightness display disappears.
NOTE: 19 inch LCD is ONLY a brightness adjustment.
8-2-10-5 Software Option Check
1.) Touch Utility > Admin.
2.) Click on System Admin tab and verify that HW Number is the same as the Option Dongle ID.
Figure 8-97 19 inch LCD Monitor Adjustment buttons
Figure 8-98 HW Number
12 3
