5-6 Chapter 5
Dx50/Dx60 Front Panel LCD Codes
Table 5-3 Major Code 1, Selftests and Diagnostics (CPU/TLB)
Ostat Code Description (Where x = CPU number)
TEST 1x30 Starting early selftest
WARN 1x31 Early selftest skipped
INIT 1x3C Initialize the CPU
TEST 1x3E Exiting early selftest
FLT 1x32 Bad CPU test mode
FLT 1x3F Cache load fault
TEST 1x40 Starting CPU basic selftest
FLT 1x40 - 1048 CPU basic selftest failure
TEST 1x49 Starting CPU ALU selftest
FLT 1x49 - 1050 CPU ALU selftest failure
TEST 1x51 Starting CPU branch selftest
FLT 1x51 - 1058 CPU branch selftest failure
TEST 1x59 Starting CPU side effect selftest
FLT 1x59 - 105A CPU side effect selftest failure
WARN 1x61 Starting CPU carry/borrow selftest
FLT 1x61 - 1066 CPU carry/borrow selftest fault
TEST 1x67 Starting CPU arithmetic condition selftest
FLT 1x67 - 1075 CPU arithmetic condition selftest fault
TEST 1x76 Starting CPU bit operation selftest
FLT 1x76 - 1077 CPU bit operation selftest fault
TEST 1078 CPU SAR selftest
FLT 1x78 - 1x79 CPU SAR selftest fault
TEST 107A Starting CPU extract/deposit selftest
FLT 1x7A - 1x80 CPU extract/deposit selftest fault
TEST 1081 Starting CPU branch on bit selftest
FLT 1x81 - 1x83 CPU branch on bit selftest fault
TEST 1x84 Starting CPU control register selftest
FLT 1x84 - 1x89 CPU control register selftest fault
TEST 1x8B Starting CPU external interrupt selftest
