10-40 Chapter 10

Removal and Replacement Procedures

Remove the Power Supply (R Class)

1. Disconnect all power cables from the extension cables.

NOTE This step requires snips to cut the tie wrap on the power cables.

2. Remove four (4) mounting screws on the rear of the chassis.

3. Lift the power supply out.

Replace the Power Supply (R Class)

1. Secure the power supply to the chassis using the four mounting screws.

2. Connect the power supply cables to the extension cables

NOTE The power supply cables must be tie wrapped.
