Chapter 10 10-35

Removal and Replacement Procedures

Replace Single-Ended SCSI Hard Disks

NOTE Before installing the disk drive check the jumper settings.

Refer to Figure 10-23.

1. Mount the replacement disk drive on the disk mounting tray.

2. Insert and tighten four screws to secure the disk drive to the mounting tray.

3. Slide the disk drive assembly into the lower peripheral bay along the tray guides.

4. Insert and tighten the two screws that secure the disk drive assembly at the front of the chassis.

5. Reconnect the power and SCSI ribbon cables to the rear of the disk drive.
