Chapter 7 7-11

Dx20/Dx30 Front Panel LCD Codes

Major Code Category 5: Bus Transactions

Table 7-7 Bus Transactions

Ostat Code Description

FLT 5000 Unknown bus fault

FLT 500A Illegal response

FLT 504F Processor memory access fault

FLT 505F Processor I/O access fault

FLT 506F HPMC due to bus error, CPU as slave

FLT 507F HPMC due to bus error, CPU as master
