12-16 Chapter 12
Remote Management/Access Port Card
Access Port Errors
Remote Management/Access Port Card
The Remote Management/Access Port (AP) card is standard on the D3xx and optional on the D2xx
and R3x0 computers. If present, the AP card executes a selftest at power on, or a user initiated selftest
(TA) can be launched from the Access Port Commands list of commands. Table 12-5 is a list of
informational and error messages associated with the AP card:
Table 12-5 AP Card Message and Error Codes
Code Message and Cause
Informational Messages
01 All tests passed. (APMSG 01)
The Access Port has executed all tests and none have terminated with a fatal
error.
02 SPU hardware was successfully reset. (APMSG 020)
Reset signal was sent to the Processor.
04 String was truncated to 23 characters. (APMSG 04)
Only 23 displayable characters are permitted in the answer to the query on the
screen. All characters past the 23rd were discarded. If the displayed string is
acceptable, NO action is necessary. If the displayed string is not acceptable,
re-execute the command and change it at the appropriate prompt.
05 AP configuration lost. Use CA and ER commands to recover. (APMSG 05)
If this message reoccurs after each reset or power on, then the AP is bad,
replace the Core I/O card.
06 SE terminated: returning to console/control mode. (APMSG 06)
The remote console operator terminated the connection it had initiated with
the SE command. The AP is reconnecting the port as a remote console. This
message can also appear after SE is typed if the previous SE session was not
cleanly terminated (the modem hung up before the operator could type "exit").
In this case, just hit break and type SE again.
Error Messages
02 Cannot verify deassertion of POW_ON signal. (APERR 02)
The AP tried to de-assert the POW_ON signal, but doe not see it de-asserted
when reading it back. Replace the Core I/O card.
