5-22 Chapter 5

Dx50/Dx60 Front Panel LCD Codes

Major Code Category A: Boot Device Initialization

Errors

Table 5-12 Boot Device Initialization Errors

Ostat Code Description

FLT A088 No console found, unable to boot

WARN A008 No bootable device found

WARN A50F Initialize primary path failed boot

WARN A70F Initialize other boot path failed

WARN A00F Retrieve path failed

WARN A0BD Entry Initialization returned a -8, device not ready

FLT A0FF Unknown launch fault (control returned from IPL)
