Chapter 11 11-7

SCSI Peripherals and I/O Information

Table 11-2 68-Pin SCSI Cable

Ground 25 49 50 50 - I/O

Signal Name

Connector

Contact

Number

Cable

Conductor

Number

Cable

Conductor

Number

Connector

Contact

Number

Signal Name

+DB(12)11235-DB(12)

+DB(13)23436-DB(13)

+DB(14)35637-DB(14)

+DB(15)47838-DB(15)

+DB(P1)5 9 1039-DB(P1)

Ground6 111240Ground

+DB(0)7 131441-DB(0)

+DB(1)8 151642-DB(1)

+DB(2)9 171843-DB(2)

+DB(3) 10 19 20 44 -DB(3)

+DB(4) 11 21 22 45 -DB(4)

+DB(5) 12 23 24 46 -DB(5)

+DB(6) 13 25 26 47 -DB(6)

+DB(7) 14 27 28 48 -DB(7)

+DB(P) 15 29 30 49 -DB(P)

DIFFSENS 16 31 32 50 Ground

TermPwr17333451TermPwr

TermPwr18353652TermPwr

Reserved 19 37 38 53 Reserved

+ATN 20 39 40 54 -ATN

Ground 21 41 42 55 Ground

+BSY 22 43 44 56 -BSY

+ACK 23 45 46 57 -ACK

+RST 24 47 48 58 -RST

Signal Name

Connector

Contact

Number

Cable

Conductor

Number

Cable

Conductor

Number

Connector

Contact

Number

Signal Name
