A-2 Appendix A

System Specifications

Table A-3 AC Electrical Specifications for 450W Power Supply

AC Input Line Frequency 50 or 60 Hz

AC Input Current

7.0 A (max. load at 100 VAC)

4.0 A (max. load at 200 VAC)

AC Inrush Current

56 A peak @ 115 VAC, 2.5ms

115 A peak @ 230 VAC, 1.8ms

AC Input Power 420 watts maximum

Power Supply Output Rating 350 watts DC continuous

Holdup Without System Reset

20ms @ 115 VAC

10ms @ 90 VAC

Description Specification

AC Input Voltage Range 90 to 140 VAC or 198 to 264 VAC

AC Input Line Frequency 50 or 60 Hz

AC Input Current

8.0 A (max. load at 100 VAC)

5.0 A (max. load at 200 VAC)

AC Inrush Current

40 A peak @ 115 VAC, 2ms

60 A peak @ 230 VAC, 1ms

AC Input Power 480 watts maximum

Power Supply Output Rating 450 watts DC continuous

Holdup Without System Reset

20ms @ 115 VAC

10ms @ 90 VAC
