B-40 Appendix B

Support Information

PDC Update Procedures

This section documents the methods that can be used for distributing Processor Dependent Code

(PDC) updates for the HP 9000 D class and R Class systems. Also included in this section are

procedures for creating a PDC update tape, verifying your current version of PDC, and a PDC update

procedure.

The topics described in this section are in the following order:

1. Current version verification

a. With on-line diagnostics

b. With boot console handler (BCH)

2. PDC distribution

a. HP Electronic SupportCenter (HPESC) access

b. Support Media

3. Creating a FIRMWARE/PDC update tape

a. From HPESC

b. From the Support Media

4. PDC update procedure

a. Updating from a tape created using HPESC files

b. Updating from a tape created using Support Media
