Dx50/Dx60 Front Panel LCD Codes

Table 5-4 Major Code 1, Boot Errors (Forward Progress)

Ostat Code Description (Where x = CPU number)

FLT 1xBA Bad Monarch CPU

FLT 1xBB Bad CPU number. CPU number not 0 or 1.

FLT 1xBC Bad CPU clock speed detected.

FLT 1xBD CPUs not installed in sequential order.

FLT 1xBF Slave CPU halted due to catastrophic boot failure

INIT 1xCA Initializing runway CPU arbitration

FLT 1xCB Mismatched CPU revisions

FLT 1xCC Mismatched cache sizes

WARN 1xCD CPU was deconfigured

FLT 1xCE CPU was stopped via PDC_PROC call

FLT 1xCF Slave halted itself when selftest status %<0

WARN 1xDy Monarch (x) deconfigured slave (y)

FLT 1xDF Monarch failed dual-issue test

WARN 1xEF Selftest returned a warning

WARN 1xFy Monarch (x) stopped a non-responding slave (y)

INIT 1xFC Synchronizing CPUs

FLT 1xFF Monarch Selftest returned a failure
