Dx20/Dx30 Front Panel LCD Codes
Major Code Category 2: Cache (Selftests and
Diagnostics)
Table 7-3 Cache (Selftests and Diagnostics) Codes
Table 7-4 Second Level Cache (Selftests and Diagnostics) Codes
Ostat Code Description
TEST 2030 Starting instruction cache tag selftest
FLT 2031 - 2034 Instruction cache tag fault
TEST 2040 Starting cache ierr selftest
FLT 2041-2045 Cache ierr fault
TEST 2080 Starting data cache tag selftest
FLT 2081 - 2084 Data cache tag fault
TEST 2090 Starting instruction cache data and tag parity selftest
FLT 2091-2095 Cache derr fault
TEST 20A0 Starting PM cache selftest
FLT 20A1-20A8 PM cache selftest fault
FLT 20B0 Dcache parity error
FLT 20C0 Icache parity error
Ostat Code Description
TEST 2100 SLC address lines selftest
FLT 2101-2102 SLC address lines selftest faults
TEST 2110 SLC cache data lines selftest
FLT 2111 SLC cache data lines selftest fault
TEST 2120 SLC selftest
FLT 2121 P1 data fault in SLC card slot B
FLT 2122 P1 data fault in SLC card slot A
FLT 2123 P1 data miss from SLC
FLT 2124 P1 SLTEADD address mismatch
FLT 2125 P1 xbyte fault in SLC card slot B
FLT 2126 P1 xbyte fault in SLC card slot A
