SCSI Peripherals and I/O Information

Table 11-26 . J5 Auxiliary and J6 Jumper Description

Preventative Maintenance

There is no preventative maintenance required for this product.

Troubleshooting

This product is considered a single FRU, the drive busy LED is only used to show activity.

Diagnostics

SCSIDSK2

Replacement Part Number

A3349-69001

TP TP Meaning

Off Off No terminator power is connected to drive terminators or

SCSI Bus pin 26.

Off On Drive supplies terminator power to internal terminator

circuits only.

On Off Drive supplies terminator power to SCSI Bus pin 26,

none to internal circuits.

On On Drive supplies terminator power to SCSI Bus pin 26 and

internal circuits (Default setting).

A2, A1, A0 Drive ID on SCSI Bus (J1-Auxiliary or J6 may be used as the ID circuits are

wired in parallel). The drive ID is binary coded positionwise; i.e., A2=ID4,

A1=ID2, and A0=ID1.
