Chapter 5 5-29

Dx50/Dx60 Front Panel LCD Codes

Major Code Category D: HP-UX System Shutdown

Codes

Table 5-17 HP-UX System Shutdown Codes

Code Description

D000 Shutdown begun, boot () has been entered

D004 Transfer of Control (TOC) core dump begun

D010 High priority machine check (HPMC) core dump begun

D400 Shutdown in progress, returned from update (), about to wait for buffers to

be flushed

D600 Shutdown in progress, busy-wait after update () has completed

D900 Shutdown completed, disks not fully synchronized

D904 TOC dump completed, disks not synchronized)

D910 HPMC completed, disks not synchronized

DA00 Shutdown completed, disks fully synchronized
