Chapter 11 11-85

SCSI Peripherals and I/O Information

Disk Specifications

Table 11-35 1, 2, 4, and 9 Gb Hot-Plug Disk Drive Modules Specifications

Table 11-36 1, 2, 4, and 9 Gb Hot-Plug Disk Drive Modules Replacement/Exchange Part Numbers

Capacity

Product

Number

Spindle

Speed

Vendor ID

String

Product ID

String

Product

Revision

1 Gb A3305A 5400 SEAGATE ST3123W HPM4

2 Gb A3306A 7200 SEAGATE ST32550W

ST32171W

ST32272W

HP06

HPM2

HP03

4 Gb A3643A 7200 SEAGATE ST34371W

ST34572W

ST34573W

HPM2

HP03

HP05

9 Gb A4910A 7200 SEAGATE ST39173 HP05

Capacity

Replacement Part

Number

Exchange Part Number

1 Gb A3315-67001 A3315-69001

2 Gb A3318-67001

A3318-67002

A3318-69001

A3318-69002

4 Gb A3647-67001 A3647-69001

9 Gb A4910-67001 A4910-69001
