Chapter 10 10-45
Removal and Replacement Procedures
Remove and Replace the Power Switch
Remove the Power Switch
1. Remove the keyed power switch connector from the System/Core I/O Board.
2. Depress the two spring-loaded tabs on the power switch.
3. Pull the power switch and cable assembly out of the chassis.
Replace the Power Switch
1. Insert the power switch assembly into the chassis.
2. Push the assembly in until the tabs snap into place.
3. Insert the keyed power switch connector into the proper connector on the System/Core I/O Board.
Replace the Side or Top Panel
Refer to Figure 10-27 and Figure 10-28.
1. Position the hinge tabs on the side panel so that they go into the four slots at the rear of the system
cabinet.
2. Lower the side panel until the hinge tabs are firmly resting in the slots,
3. Close the side panel.
4. Align and tighten the three captive screws.
Replace the Front Bezel
Refer to Figure 10-29.
1. Hook the tabs on the top of the bezel into the slots on the top edge at the front of the system
cabinet, and swing the bezel downward.
2. Push the bottom of the bezel against the chassis until the bezel snaps into place.
