9-6 Chapter 9

Replaceable Parts

Table 9-4 HSC Assemblies

New HP Part

Number

Exchange HP

Part Number

Description

A2679-60002 J3516-69004 100Bt Dual Port LAN

J3516-60024 N/A 100Bt Dual Port LAN

(Fibre)

J3516-60034 J3516-69034 100Bt Single Port LAN

J2499-60021 N/A ATM 155 (Fibre)

J2499-60011 N/A ATM 155 (UTP5)

A3395-60001 A3395-69001 1063-Mbps FC Adapter

A3723-60001 A3726-69001 FDDI LAN Adapter

A4925-60001 A4925-69001 Gigabit Ethernet
