PD Requested Power Value : 0.0 W PSE TLV Sent Type : MED
MED LLDP Detect : Disabled PD TLV Sent Type : n/a
LLDP Dual Signature Information
PSE Allocated Power Value A : 25.5 W PSE Allocated Power Value B : 25.5 W
PD Requested Power Value A : 0.0 W PD Requested Power Value B : 0.0 W
Power Information
PSE Voltage : 55.0 V PSE Reserved Power : 57.4 W
PD Amperage Draw : 890 mA PD Power Draw : 49.2 W
Example show command output at a port for a Single Signature PD.
Aruba-2930M-40G-8SR-PoE-Class6(slot 1)$ show pow 14
Status and Configuration Information for port 14
Power Enable : Yes PoE Port Status : Delivering
PLC Class/Type : 3/3 Priority Config : low
DLC Class/Type : 0/- Pre-std Detect : off
Alloc By Config : usage Configured Type :
Alloc By Actual : usage PoE Value Config : n/a
PoE Counter Information
Over Current Cnt : 0 MPS Absent Cnt : 0
Power Denied Cnt : 0 Short Cnt : 0
LLDP Information
PSE Allocated Power Value : 8.3 W PSE TLV Configured : dot3, MED
PD Requested Power Value : 0.0 W PSE TLV Sent Type : dot3
MED LLDP Detect : Disabled PD TLV Sent Type : n/a
Power Information
PSE Voltage : 54.0 V PSE Reserved Power : 9.0 W
PD Amperage Draw : 151 mA PD Power Draw : 8.4 W
Example of show lldp info loc/remote port
A Dual Signature PD is connected to the 2930M .3bt switch:
LLDP Local Port Information Detail
Port : 1/1
PortType : local
PortId : 1
PortDesc : 1/1
Pvid : 1
Poe Plus Information Detail
Poe Device Type : Type2 PSE
Power Source : Primary
Power Priority : Low
PD Requested Power value : 25.5 Watts
PSE Allocated Power Value : 0.0 Watts
PD Requested Power value Mode A : 25.5 Watts
PSE Allocated Power Value Alt A : 12.7 Watts
PD Requested Power value Mode B : 25.5 Watts
PSE Allocated Power Value Alt B : 12.7 Watts
PoE Event Log messages
Please see the event log message reference guide for information about Event Log messages. To see these
manuals, go to http://www.hpe.com/networking. Auto search the model number for your switch, for Example:
Chapter 4 Power Over Ethernet (PoE/PoE+) Operation 127
