USERNAME-STR

A username for ACS authentication (maximum length: 256 characters).

Enable/disable CWMP

Syntax:

cwmp [enable|disable]

Show commands

CWMP configuration and status query

Syntax:

show cwmp

configuration

Show current CWMP configuration.

status

Show current CWMP status.

When CWMP is enabled

Syntax:

show cwmp configuration

CWMP configuration

CWMP Configuration

CWMP Status : Enabled

ACS URL : http://16.93.62.32:9090

ACS Username : bims

Inform Enable Status : Enabled

Inform Interval : 60

Inform Time : 2014-04-08T06:00:00

Reconnection Timeout : 30

CWMP status

CWMP Status

CWMP Status : Enabled

ACS URL : http://16.93.62.32:9090

ACS URL Origin : Config

ACS Username : bims

Connection Status : Disconnected

Data Transfer Status : None

Last ACS Connection Time : Wed Apr 9 16:56:00 2014

Time to Next Connection : 00:00:36

760 Aruba 2930F / 2930M Management and Configuration Guide
