Usage

• To show system fans, see show system fans

• To show chassis power supply and settings, see show system power-supply

• To show system fans for VSF members, see show system fans vsf

Examples

Locating the system chassis by LED blink using the show system chassislocate command.

Showing the general switch system information by using the show system command.

show system fans

Syntax

show system fans

Description

Shows the state, status, and location of system fans.

Command context

manager and operator

450 Aruba 2930F / 2930M Management and Configuration Guide

for ArubaOS-Switch 16.08
