Viewing all mirroring session configured on the switch
Syntax
show monitor
If a monitored source for a mirror session is configured on the switch, the following information is displayed.
Otherwise, the output displays: Mirroring is currently disabled. Mirror port configured on the switch is shown:
switch(config) # show monitor
Network Monitoring Port
Mirror Port: 16
Monitoring sources
------------------
2
5
Viewing the remote endpoints configured on the switch
Syntax
show monitor endpoint
Displays the remote mirroring endpoints configured on the switch. Information on local sessions configured on the
switch is not displayed. (To view the configuration of a local session, use the show monitor [1-4 | name
<name-str>] command)
Type Indicates whether the session is a port (local) or IPv4 (remote) mirroring session.
show monitor
endpoint
The IP address configured for the source VLAN or subnet on which the monitored source
interface exists. In the configuration of a remote session, the same UDP source address
must be configured on the source and destination switches.
UDP port The unique UDP port number that identifies a remote session. In the configuration of a
remote session, the same UDP port number must be configured on the source and
destination switches.
UDP Dest Addr The IP address configured for the destination VLAN or subnet on which the remote exit port
exists. In the configuration of a remote session, the same UDP destination address must be
configured on the source and destination switches.
Dest Port fies the exit port for a remote session on a remote destination switch.
Example
418 Aruba 2930F / 2930M Management and Configuration Guide
for ArubaOS-Switch 16.08
