VSF port LEDs
Table 41: VSF port LEDs
Global Status LED Mode LED Usr Port LED Diagnostic tips
Solid green Solid green Solid orange See LED 1 and LED 2
display solid green
color, whereas, LED 3
displays solid orange on
page 702
Slow flash orange Solid green Slow flash green-
MemberFast flash green-
CommanderSolid green-
Member with good
stacking connectionSlow
flash orange-Member with
poor stacking connection
See LED 1 displays slow
flash orange, LED 2
displays solid green,
whereas, LED 3 displays
different colors on page
703
Slow flash orange Solid green Slow flash green-
MemberFast flash green-
CommanderSlow flash
orange-Member in another
fragment
See LED 1 displays slow
flash orange and LED 2
displays solid green
color, whereas, LED 3
displays different colors
on page 704
Solid green Solid green Slow flash green-
MemberFast flash green-
Commander
See LED 1 and LED 2
display solid green,
whereas, LED 3 displays
different colors on page
704
Solid green Solid green Slow flash green-
MemberFast flash green-
Commander
See LED 1 and LED 2
display solid green,
whereas, LED 3 displays
different colors on page
704
Diagnostic tips for stacking error
LED 1 and LED 2 display solid green color, whereas, LED 3 displays solid orange
Symptom
LED 1 and LED 2 display solid green color, whereas, LED 3 is off.
1
1
LED 1 is Global Status LED, LED 2 is Mode LED Usr, and LED 3 is Port LED.
Cause
Stacking is disabled on the switch. The member is unreachable or booting.
702 Aruba 2930F / 2930M Management and Configuration Guide
for ArubaOS-Switch 16.08
