Table 39: Supported ring topologies

Members Ring topology

3–member

4–member

5–member

6–member

7–member

8–member

Running-configuration synchronization

VSF uses a strict running-configuration synchronization mechanism. In a VSF fabric, the Commander manages

and retains the configuration of all the devices. All other devices obtain and use the running configuration from the

Commander.

654 Aruba 2930F / 2930M Management and Configuration Guide

for ArubaOS-Switch 16.08
