INFORMATION
B2650HSDC, B3350HSDC, WSM
I-8
3. SPECIFICATIONS
• * Manufacturer's estimate
The company reserves the right to change the specifications without notice.
9Y1210822INI0006US0
Model B2650HSDC B3050HSDC
PTO power* 14.5 kW (19.5 HP)* 20.1 kW (27.0 HP)*
Engine
Maker KUBOTA
Model D1305-E4-D26-Q V1505-T-E4-D26-Q
Type Indirect Injection, Vertical, water-cooled, 4 cycle diesel
Number of cylinders 3 4
Bore and stroke 78 × 78.4 mm (3.1 × 3.1 in.)
Total displacement 1261 cm
3
(77.0 cu.in.) 1498 cm
3
(91.5 cu.in.)
Engine gross power* 19.4 kW (26.0 HP)* 24.6 kW (33.0 HP)*
Rated revolution 2500 min
-1
(rpm)
Low idling revolution 1100 min
-1
(rpm)
Maximum torque 84.0 N·m (8.6 kgf·m, 62.0 lbf·ft) 105.4 N·m (10.75 kgf·m, 77.74 lbf·ft)
Battery 12 V, RC: 80 min, CCA: 430 A
Capacities
Fuel tank 27 L (7.1 U.S.gals, 5.9 Imp.gals)
Engine crankcase (with filter) 4.0 L (4.2 U.S.qts, 3.6 Imp.qts) 4.8 L (5.1 U.S.qts, 4.2 Imp.qts)
Engine coolant 4.3 L (4.5 U.S.qts, 3.8 Imp.qts)
Transmission case 15 L (4.0 U.S.gals, 3.3 Imp.gals)
Dimensions
Overall length (without 3P) 2900 mm (114.2 in.)
Overall width 1365 mm (53.7 in.)
Overall height 2150 mm (84.6 in.)
Wheel base 1666 mm (65.6 in.)
Min. ground clearance 370 mm (14.6 in.)
Tread
Front 935 mm (36.8 in.)
Rear 1050 mm (41.3 in.)
Weight 1040 kg (2293 lbs) 1110 kg (2447 lbs)
Traveling
system
Clutch –
Tread
Front 7-12
Rear 12.4-16
Steering Hydrostatic type power steering
Transmission Main-hydrostatic transmission, 3 range gear shift (3 forward, 3 reverse)
Brake Wet disc type
Min. turning radius
(with brake)
2.1 m(6.9 feet)
Hydraulic unit
Hydraulic control system Position control
Pump capacity 33.1 L/min (8.7 U.S.gals/min, 7.3 Imp.gals/min)
3-point hitch SAE Category 1
Max. lift force
At lift points 970 kg (2139 lbs)
24 in. behind
lift point
760 kg (1676 lbs)
PTO
Rear-PTO SAE 1-3/8, 6 splines
PTO / Engine speed 1 speed 563 / 2500 min
-1
(rpm)
Rear-PTO USA No. 5 (KUBOTA 10-tooth) involve spline
PTO / Engine speed 1 speed 2500 / 2500 min
-1
(rpm)
To Next Page
