STEERING
B2650HSDC, B3350HSDC, WSM
6-S2
2. SERVICING SPECIFICATIONS
POWER STEERING BODY
POWER STEERING CYLINDER
9Y1210822STS0002US0
Item Factory Specification Allowable Limit
Relief Valve Setting Pressure 10.8 to 11.3 MPa
111 to 115 kgf/cm
2
1570 to 1630 psi
(at 12 ± 0.5 L/min.)
–
Item Factory Specification Allowable Limit
Steering Cylinder I.D. 40.000 to 40.062 mm
1.5748 to 1.5772 in.
40.100 mm
1.5787 in.
Piston Rod to Guide Clearance 0.020 to 0.070 mm
0.00079 to 0.0027 in.
0.200 mm
0.00787 in.
To Next Page
