STEERING
B2650HSDC, B3350HSDC, WSM
6-S3
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts : See page G-11.)
9Y1210822STS0003US0
Item N·m kgf·m lbf·ft
Power steering hose for power steering cylinder 24 to 28 2.5 to 2.8 18 to 20
Power steering controller for hoses 24 to 28 2.5 to 2.8 18 to 20
Tie-rod slotted nut 18 to 35 1.9 to 3.5 14 to 25
Tie-rod joint 74 to 84 7.6 to 8.5 55 to 61
To Next Page
