ELECTRICAL SYSTEM
B2650HSDC, B3350HSDC, WSM
8-M14
5. DIGITAL DISPLAY
This display shows the following information
• Tractor information, such as engine speed, PTO rpm, hours the tractor has been operated and error code can be
displayed.
9Y1210822ELM0021US0
[1] LCD MONITOR INDICATOR
Fuel Gauge, Coolant Temperature Gauge,
Hourmeter and Tachometer
• With key switch at "ON", the fuel gauge and coolant
temperature gauge indicate the fuel level and
temperature of the coolant.
• The tachometer indicates the engine speed and the
PTO shift speed location on the dial.
• The hourmeter indicates in five digits the hours.
The tractor has been used; the last digit indicates
1/10 of an hour.
9Y1210822ELM0022US0
(1) Fuel Gauge
(2) Coolant Temperature Gauge
(3) Engine Revolution / PTO
Speed Indictor
(4) Hours Used Indicator
To Next Page
