FRONT AXLE
B2650HSDC, B3350HSDC, WSM
5-S3
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts: See page G-11.)
9Y1210822FAS0003US0
Item N·m kgf·m lbf·ft
Front wheel mounting nut 77 to 90 7.9 to 9.2 57 to 67
Front axle bracket mounting screw 200 to 230 20.4 to 23.4 148 to 169
Bevel gear case mounting screw 77.5 to 90.1 7.9 to 9.2 57.1 to 66.5
Axle flange mounting screw 48.1 to 55.9 4.9 to 5.7 35.5 to 41.2
Delivery hose retaining nut 24 to 28 2.5 to 2.9 17.7 to 20.7
Tie-rod slotted nut 18 to 35 1.9 to 3.5 14 to 25
Tie-rod joint 74 to 84 7.5 to 8.6 54.4 to 61.9
