GENERAL
B2650HSDC, B3350HSDC, WSM
G-59
[4] TIRE LIQUID INJECTION
Auxiliary weights can be used to increase traction force for plowing in fields or clayey grounds.
Another way is to inject water or another liquid, such as a calcium chloride solution in the tires. Water must not
be used in winter since it freezes at 0 °C (32 °F). The calcium chloride solution will not freeze and moreover, affords
higher effect than water since its specific gravity is higher than that of water by about 20 %. Below is an explanation
of calcium chloride solution injection.
• Do not fill the front tires with liquid.
9Y1210822GEG0089US0
Preparation of Calcium Chloride Solution
• When making a calcium chloride solution, do not pour
water over calcium chloride since this results in chemical
reaction which will cause high temperature. Instead add a
small amount of calcium chloride to the water at a time until
the desired solution is achieved.
9Y1210822GEG0090US0
Attaching Injector
1. Lift the rear tires off the ground.
2. Turn the tire so that the air valve is at the top.
3. Remove the air valve, and attach the injector (Code No.
07916-52501).
9Y1210822GEG0091US0
Freezing temp.
Weight of CaCl
2
to be dissolved in 100 L
(26.4 U.S.gals, 22.0 lmp.gals) of water
−5 °C (23 °F) 12 kg (26 lbs)
−10 °C (14 °F) 21 kg (46 lbs)
−15 °C (5 °F) 28 kg (62 lbs)
−20 °C (−4 °F) 34 kg (75 lbs)
−25 °C (−13 °F) 40 kg (88 lbs)
−30 °C (−22 °F) 44 kg (97 lbs)
−35 °C (−31 °F) 49 kg (110 lbs)
−40 °C (−40 °F) 52 kg (115 lbs)
−45 °C (−49 °F) 56 kg (120 lbs)
−50 °C (−58 °F) 61 kg (130 lbs)
(a) Water (b) CaCl
2
(Calcium Chloride)
(1) Injector (2) Hose
To Next Page
