FRONT AXLE
B2650HSDC, B3350HSDC, WSM
5-S2
2. SERVICING SPECIFICATIONS
9Y1210822FAS0002US0
Item Factory Specification Allowable Limit
Front Wheel Alignment Toe-in 0 to 10 mm
0 to 0.39 in.
–
Front Axle Rocking Force 50.0 to 100 N
5.1 to 10.2 kgf
11.3 to 22.4 lbf
–
Differential Pinion to Deferential Case
• Differential Case Bore
• Differential Pinion
Clearance
I.D.
O.D.
0.032 to 0.068 mm
0.0013 to 0.0026 in.
15.000 to 15.018 mm
0.59056 to 0.59125 in.
14.950 to 14.968 mm
0.58859 to 0.58929 in.
0.2 mm
0.008 in.
–
–
Yoke Shaft to Differential Case
• Differential Case Bore
• Yoke Shaft
Clearance
I.D.
O.D.
0.020 to 0.051 mm
0.00079 to 0.0020 in.
20.000 to 20.018 mm
0.78741 to 0.78811 in.
19.967 to 19.980 mm
0.78611 to 0.78661 in.
0.2 mm
0.008 in.
–
–
Spiral Bevel Pinion Shaft Turning Torque 0.8 to 1.0 N·m
0.08 to 0.10 kgf·m
0.59 to 0.73 lbf·ft
–
Spiral Bevel Pinion Shaft to Spiral Bevel
Gear
Backlash 0.10 to 0.30 mm
0.0039 to 0.0118 in.
–
11T Bevel Gear to 16T Bevel Gear Backlash 0.10 to 0.30 mm
0.0039 to 0.0118 in.
–
Front Axle Case Boss to Bracket Bushing
(Front)
• Front Axle Case Boss
• Bracket Bushing
Clearance
O.D.
I.D.
0.120 to 0.275 mm
0.00493 to 0.0108 in.
49.950 to 49.975 mm
1.9666 to 1.9675 in.
50.095 to 50.225 mm
1.9723 to 1.9773 in.
0.45 mm
0.018 in.
–
–
Front Axle Case Boss to Bracket Bushing
(Rear)
• Front Axle Case Boss
• Bracket Bushing
Clearance
O.D.
I.D.
0.120 to 0.300 mm
0.00473 to 0.0108 in.
65.005 to 65.035 mm
2.5593 to 2.5604 in.
65.155 to 65.305 mm
2.5652 to 2.5710 in.
0.45 mm
0.018 in.
–
–
KiSC issued 05, 2014 A
