CABIN
B2650HSDC, B3350HSDC, WSM
9-S5
2. SERVICING SPECIFICATIONS
9Y1210822CAS0002US0
Item Factory Specification Allowable Limit
Kinds of refrigerant Charge Amount R134a
650 to 710 g
1.44 to 1.56 lbs
–
Refrigerating Cycle
(Refrigerating Cycle is Normal Operating)
Pressure
(LO Pressure Side)
Pressure
(HI Pressure Side)
0.15 to 0.20 MPa
1.5 to 2.0 kgf/cm
2
21 to 28 psi
1.27 to 1.66 MPa
13 to 17 kgf/cm
2
185 to 242 psi
–
–
A/C Compressor Magnetic Clutch Air-gap 0.30 to 0.65 mm
0.012 to 0.025 in.
–
Air Conditioner Drive Belt Tension 10 to 12 mm
(0.39 to 0.47 in.)
deflection at 98 N
(10 kgf, 22 lbf) of force
–
Pressure Switch (Dual Type)
(When pressure switch is turned OFF)
Setting Pressure
(LO Pressure Side)
Setting Pressure
(HI Pressure Side)
Less than
approx.
0.196 MPa
2.0 kgf/cm
2
28.4 psi
More than
approx.
3.14 MPa
32 kgf/cm
2
455 psi
–
–
Number of Wiper Arm Swing Frequency At No Load 33 to 43 times/min. –
Wiper Blade Position Approx.
150 mm
5.91 in.
–
To Next Page
