GENERAL
B2650HSDC, B3350HSDC, WSM
G-30
Cleaning Air Filter
Fresh Air Filter
1. Remove the knob bolts (3) and pull out the fresh air filter (1).
2. Blow air from the opposite direction to the filter's normal air flow.
Pressure of compressed air must be under 205 kPa
(2.1 kgf/cm
2
, 30 psi).
• If the filter is very dirty:
Dip the filter in lukewarm water with mild dish washing
detergent.
Move it up and down as well as left and right to loosen dirt.
Rinse the filter with clean water and let it air-dry.
• Do not use gasoline, thinner or similar chemicals to clean
the filter as damage to the filter may occur.
• If may also cause an unpleasant odor in the CABIN when
the system is used next.
• Do not hit the filter. If the filter becomes deformed, dust
may enter into the air-conditioner, which may cause
damage and malfunction.
9Y1210822GEG0042US0
Checking Air Conditioner Condenser
1. Check the air conditioner condenser (1) to be sure that it is clean
of debris.
9Y1210822GEG0043US0
[6] CHECK POINTS OF EVERY 300 HOURS
Changing Transmission Fluid
• See page G-20.
9Y1210822GEG0044US0
(1) Fresh Air Filter
(2) Cover
(3) Knob Bolt
A: Air Inlet Port
B: Air Conditioner Air Flow
(1) Air Conditioner Condenser
