3. In the "Materials" tab, specify the following:
– Name of the material
– Unique alphanumeric code (string) for the material
– Whether it is an input and/or output material
4. Select the "Qualities" tab.
5. Add new qualities with the "New" button. Several qualities are possible for a material.
Note
Qualities for a material
The definition of qualities for a material is optional.
6. Confirm the new materials you have made with "OK".
Note
Shortcut menu for the "Materials" folder
As an alternative, you can also make these settings with the commands "New" and
"Properties" in the shortcut menu for the "Materials" folder in the tree.
Modifying and deleting
Using the shortcut menu commands "Properties" and "Delete" you can modify or delete existing
materials.
9.4.2 Changing the quality
Proceed as follows:
1. Select the quality BatchCC (in the "Materials" folder).
2. Select the menu command Edit > Properties.
3. Change the settings for the quality in the "Quality" dialog.
4. Save you new entries with "OK".
Note
Context menu for the "Quality" object
As an alternative, you can also perform this settings in the tree using the command
Properties in the context menu of the object .
BATCH Control Center
9.4 Specifying the materials
SIMATIC BATCH V8.2
294 Operating Manual, 02/2016, A5E35958174-AA
