Cancel button
Closes the dialog without saving changes.
Help button
Opens the SIMATIC BATCH online help for this context.
See also
"Chart folder" tab (Page 949)
14.1.12.3 "S7 program" selection
In the Process cell data list you have selected the "S7 program" object. The S7 program is
assigned to a CPU in an automation system. The name displayed as the folder name is the
name you assigned in the basic engineering in the SIMATIC Manager.
Runtime name in the dialog header
Logical path within the navigation tree.
Process cell data
For navigation in the process cell data
Properties
Name of the object selected in the process cell tree.
Description Information about the selected object is displayed in this text field. If you en‐
tered a comment for the object in the properties in the basic engineering, this
is displayed here.
Last changed on This text box displays the date and time of the last change in the following
format:
Example: 09/15/2010 08:24:47 (UTC +2:00), Coordinated Universal Time.
The entries "UTC +X" or "UTC -X" specify the current actual difference be‐
tween the national time and UTC.
Logical path The S7 program logical path is displayed in this text field.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
860 Operating Manual, 02/2016, A5E35958174-AA
