Additional functions
Display of possible additional functions.
OK button
Saves your settings and closes the dialog.
Apply button
Your settings are saved without closing the dialog. The button is only available if you have
made changes in the dialog.
Cancel button
Closes the dialog without saving changes.
Help button
Opens the SIMATIC BATCH online help for this context.
14.1.12.37 "Equipment module (EMOD)" selection
Equipment module selection
In the list "Process cell data" you have selected the object "Equipment module".
Display field under dialog title
Logical path display
Process cell data
For navigation in the process cell data
Properties
Name of the object selected in the process cell tree.
Description A description of the equipment module is displayed in this text box. You can enter a
descriptive text in the object properties for the unit in the SIMATIC Manager.
Equipment module
No function.
Context help references
14.1 Dialogs
SIMATIC BATCH V8.2
Operating Manual, 02/2016, A5E35958174-AA 915
