The "Candidates" area displays all candidates configured in the Recipe Editor that are possible
for the condition in rows in a table.
● "Unit" column: Name of the unit from the master recipe.
● "OK" column: The following symbols are displayed:
Symbol Meaning
OK, unit can be used as a possible candidate.
Not OK, unit cannot be used as a possible candidate.
Unit or its parameters invalid, not initialized or unknown.
In the "Conditions" area, the evaluations of the conditions during runtime are shown in a table
as results. The following symbols are displayed:
Symbol Meaning
OK, condition was met.
Not OK, condition was not met.
Current value or condition invalid, not initialized or unknown.
Additional information
Unit selection via conditions for a flat recipe (Page 526)
Unit selection via conditions for a hierarchical recipe (Page 527)
14.1.3.8 "Allocations" tab (Recipe procedure/Batch properties)
"Allocations" tab
This tab shows you information about allocations of units by running batches in a tabular form.
Button for printing parameters
Using a button in the table view, you can open a shortcut menu for printing the displayed
parameters. If you click the "Print" button in the shortcut menu, the table view along with the
parameters is output immediately to the default printer set in Windows.
If you click the "Print..." button, a Windows dialog opens in which you can select another printer
set up in Windows. If you click "OK" after making the selection, the parameters are printed.
