Operation 10.04
2.10 Automatic mode
2
 Siemens AG, 2004. All rights reserved
2-116 SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition
When a ShopMill program with Version 6.3 is executed in
ShopMill 6.2, it is deemed to be a Version-6.2 program.
2.10.1 Switchover between "T, F, S", "G functions" and "Auxiliary functions" displays
While the workpiece is being machined, if you want to know, for
example, whether the tool tip radius compensation is currently active
or which unit of measurement is being used, you can activate display
of the G functions or auxiliary functions.
G functions
16 different G groups are displayed under "G function". Within a G
group, only the G function currently active in the NC is displayed.
As an alternative, all G groups with all associated G functions are
listed in "All G Func.".
Auxiliary functions
Auxiliary functions include M and H functions preprogrammed by the
machine manufacturer, which pass parameters to the PLC to trigger
reactions defined by the manufacturer.
Please refer to the machine manufacturer's instructions.
A maximum of five M functions and three H functions are displayed.
When executing a sequential control program, you can display the G
functions currently active in the NC too, as the ShopMill functions are
converted to G code internally.
G function
 Press the "G function" softkey in "Machine Manual" or "Machine
Auto" mode.
Instead of parameters T, F and S, the currently active G functions
within a G group will be displayed.
If you press the "G Function" softkey again, the "T, F, S" status
display reappears.
- OR -
All
G func.
 Press the "All G func." softkey.
Instead of parameters T, F and S, all G groups with G functions are
now listed. If you select the "All G func." softkey again, the "T, F, S"
status display reappears.
- OR -
Auxiliary
function
 Press the "Auxiliary function" softkey.
Instead of parameters T, F and S, the currently active auxiliary
functions will be displayed. If you press the "Auxiliary function" softkey
again, the "T, F, S" status display reappears.
