6
File Management 10.04
6.2 Pro
ram mana
ement with PCU 20
6
ï›™ Siemens AG, 2004. All rights reserved
6-352 SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition
6.2.2 Executing a program
You can select any program that is stored in your system at any time
to machine workpieces automatically.
îš¾ Open the Program Manager.
îš¾ Place the cursor on the program that you want to execute.
Execute
îš¾ Press the "Execute" softkey.
ShopMill now switches to "Machine Auto" operating mode and
uploads the program.
Cycle Start
îš¾ Then press the "Cycle Start" key.
Workpiece machining is initiated (see also Sec. "Automatic mode".)
If the program is already open in the "Program" operating area, press
the "Execute" softkey to load the program in "Machine Auto" mode.
Then start machining of the workpiece by pressing the "Cycle Start"
key.
6.2.3 Multiple clamping
The "Multiple clamping" function provides optimized tool change over
several workpiece clampings. This shortens idle times because a tool
performs all machining operations in all clampings before the next tool
change is initiated.
You can use not only the surface clampings but also the "multiple
clamping" function for rotating fixture plates. For this, the machine
must have an additional rotary axis (e.g. A-axis) or a dividing unit.
Please refer to the machine manufacturer's instructions.
You can machine not only identical but also different workpieces with
this function.
The "Multiple clamping for different programs" function is a software
option.
