Siemens SINUMERIK 840D Operation/Programming

1
Introduction 10.04
1.2 Workstation
1
 Siemens AG, 2004. All rights reserved
1-24 SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition
+Z
+Y
+X
Right-hand rule
1.2.2 Operator panels
You can use one of the following operator panels for the PCU:
OP 010
OP 010C
OP 010S with OP 032S full CNC keyboard
OP 012
OP 015 with 19'' full CNC keyboard
Operator panel OP 010
3
4
2
1
6
.
5
2
Operator panel OP 010
1 10" screen
2 Screen keys
3 Horizontal softkey bar
4 Vertical softkey bar
• Alphanumeric keypad
Correction/cursor pad with control keys and input key
• USB interface
