Siemens SINUMERIK 840D Operation/Programming

3
10.04 Programming with ShopMill
3.5 Contour millin
g
3
 Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition 3-219
3.5.14 Finishing the contour spigot
If you programmed a finishing allowance for the base or edge of the
spigot in spigot milling, you still have to finish the spigot.
Separate blocks must be programmed for finishing the base and/or for
finishing the edge. In each case, the spigot will only be machined
once.
You can program "Path milling" as an alternative to "Edge finishing".
Optimization possibilities are also offered for the approach/retract
strategy and the approach/retract mode. Then program as follows:
1. Contour blank
2. Contour spigot
3. Mill spigot (roughing)
4. Contour blank
5. Path milling (finishing)
6. Contour spigot
7. Path milling (finishing)
Mill
spigot >
 Press the "Cont. mill." and "Mill spigot" softkeys.
 Select "Finish base" or "Finish edge" machining mode.
Parameters Description Unit
T, D, F, S, V See Sec. "Creating program blocks".
Machining
type
Finishing the base
Finishing the edge
Z0
Z1
DXY
DZ
UXY
UZ
Reference point in Z direction (abs.)
Depth with reference to Z0 (abs. or inc.)
Maximum infeed in the XY plane (base finishing only)
Plane infeed in %: Ratio of plane infeed (mm)
to milling cutter diameter (mm)
Maximum depth infeed (Z direction) – (edge finishing only)
Finishing allowance in plane
Finishing allowance in depth – (edge finishing only)
mm
mm
mm
%
mm
mm
mm
Retraction
mode
If more than one approach point is necessary, specify the retraction height to which
the tool retracts between approach points.
• To retraction plane
• Z0 + safety clearance
If there are no spigots or other elements larger than Z0 in the machining area, "Z0 +
safety clearance" can be selected as the retraction mode.
