Siemens SINUMERIK 840D Operation/Programming

2
10.04 Operation
2.10
A
utomatic mode
2
 Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition 2-117
2.10.2 Selecting a program for execution
-or-
 Press the "Program" softkey or the "Program Manager" key.
The directory overview is displayed.
 Place the cursor on the directory containing the program that you
want to select.
-or-
 Press the "Input" or "Cursor right" key.
The program overview is displayed.
 Place the cursor on the required program.
Execute
 Press the "Execute" softkey.
ShopMill automatically changes to "Machine Auto" operating mode
and uploads the program.
- OR -
-or-
 Press the "Program" softkey or the "Program Manager" key.
The directory overview is displayed.
 Place the cursor on the directory containing the program that you
want to select.
-or-
 Press the "Input" or "Cursor right" key.
The program overview is displayed.
 Place the cursor on the required program.
-or-
 Press the "Input" or "Cursor right" key.
The selected program is opened in the "Program" operating area. The
machining plan of the program is displayed.
 Place the cursor on the program block at which the program run
must begin.
 Press the "Execute" softkey.
ShopMill automatically changes to "Machine Auto" manual mode,
loads the program and conducts a block search until it reaches the
selected program block (see Sec. "Entering a program at any selected
point").
