Siemens SINUMERIK 840D Operation/Programming

1
Introduction 10.04
1.1 Sho
p
Mill
1
 Siemens AG, 2004. All rights reserved
1-20 SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition
1.1 ShopMill
ShopMill is operating and programming software for milling machines
that makes it easy for you to operate the machine and to program
workpieces.
These are some of the features the software provides:
Setting up the machine
Special measurement cycles make it easier to measure the tools and
the workpiece.
Creating a program
3 different programming methods are available:
• G code programs for mold-making applications imported from
CAD/CAM systems.
• G code programs that you create directly at the machine.
You can use all technology cycles for programming:
• Sequential control programs that you create directly at the
machine (software option).
The workpiece is programmed with ease because graphical
techniques are used and no knowledge of G codes is required.
ShopMill displays the program as a clearly understandable
process plan and presents the individual cycles and contour
elements in a dynamic graphical display.
Irrespective of the programming method you use, the following
functions will simplify programming and processing:
• A powerful contour calculator lets you enter any contours.
•
A
stock removal cycle complete with detection of residual material
saves unnecessary machining (software option).
• A swivel cycle allows multiple-surface machining and machining
on inclined surfaces, irrespective of the machine kinematics of the
machine.
Executing a program
You can display the execution of programs on the screen
three-dimensionally.
This makes it easy for you to check the result of programming and to
observe the progress of workpiece machining at the machine
(software option).
The execution of sequential control programs is a software option.
