Siemens SINUMERIK 840D Operation/Programming

5
Simulation 10.04
5.10 Distance measurement
5
 Siemens AG, 2004. All rights reserved
5-342 SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition
Panning the graphics
Details Pan
 Press the "Details" and "Pan" softkeys.
Up
...
Right
 Press the "Up", "Down", "Left", or "Right" softkey.
- OR -
 Press one of the cursor keys.
- OR -
Center
 Press the "Center" softkey.
The viewport is panned up, down, left, or right, or aligned in the center
of the screen.
5.10 Distance measurement
It is possible to measure and display the direct path (spatial diagonal)
between to points of the workpiece by marking two points in the
graphics.
Measuring distance
Details
Distance
 Press the "Details" and "Distance" softkeys.
 Move the cross-hairs to the required position.
Mark
Point A
 Press the "Mark Point A" softkey to define the first point.
Mark
Point B
 Position the cursor on the second point and press the "Mark Point
B" softkey.
The selected points are marked in the graphics.
The distance between the two points is calculated and output in the
message line below the graphics display.
Repeat this process if you wish to measure more distances.
