Siemens SINUMERIK 840D Operation/Programming

2
10.04 Operation
2.10
A
utomatic mode
2
 Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition 2-129
 Load a program in "Machine Auto" operating mode (see Sec.
"Selecting a program for execution").
 Press the "Prog. Cntrl." softkey.
Program
test
 Press the "Program test" softkey.
Cycle Start
 Press the "Cycle Start" key.
The program is tested without traversing of the machine axes.
Program
test
 Press the "Program test" softkey again to deactivate test mode on
completion of the program. (The softkey is deactivated again.)
2.10.9 Simultaneous recording before machining
In automatic mode you can display your program graphically in the
"Program test" function before machining, without traversing the
machine axes.
Simultaneous recording is a software option.
The graphic displays a workpiece as if it were being machined with a
cylindrical tool.
Status displays
The status display in the graphic contains the following information:
• Current axis coordinates
• Block currently being processed.
• The processing time (in hours/minutes/seconds)
indicates the approximate time that would actually be required to
execute the machining program on the machine (incl. tool change).
The timer is stopped if the program is interrupted.
 Select the program in "Machine Auto" mode.
Program
test
Dry run
feedrate
 Press the "Prog. Cntrl." and "Program test" softkeys.
 Also activate the "Dry run feedrate" softkey.
The programmed feedrate is replaced by a dry run feedrate defined
via machine data.
 Press the "Real-sim" softkey.
