Siemens SINUMERIK 840D Operation/Programming

6
10.04 File Management
6.2 Pro
g
ram mana
g
ement with PCU 20
6
 Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition 6-361
6.2.10 Importing/exporting a program via the RS-232 interface
Programs can be exchanged with other ShopMill stations via an
external data storage system through the RS-232 interface.
The data export function can also be used to export data that is not
currently required to release NC main memory. You can re-import the
exported programs as they are needed.
When you import or export a program into/out of ShopMill, all ShopMill
subroutines are transferred with it.
It is also possible to import or export more than one program in the
same operation.
The RS-232 interface of the control and the external data medium
must be compatible, i.e. you must make the same settings for each
RS-232 interface.
Make sure that you set the correct file format (binary/PC, punched
tape or punched tape/ISO format) on reading out. Otherwise the
partner system will not be able to interpret the data.
Exporting a program
 Open the Program Manager.
 Place the cursor on the program that you want to export.
Continue
>
Read out
 Select the "Continue" and "Read out" softkeys.
RS-232
settings
 Press the "RS-232 settings" softkey to set up the interface.
 Enter the desired settings.
 Press the "Back" softkey.
The settings for the interface are saved.
All files
 Press the "All files" softkey if you want to select all the programs
displayed.
 Start the transfer on the partner system.
Start
 Press "Start" softkey.
The selected program and all its ShopMill subroutines are exported.
The "Readout" window displays the name of the program that has just
