Siemens SINUMERIK 840D Operation/Programming

2
Operation 10.04
2.2 Reference
p
oint a
pp
roach
2
 Siemens AG, 2004. All rights reserved
2-56 SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition
2.2.1 User agreement in Safety Integrated
If you are using Safety Integrated (SI) on your machine, you will need
to confirm that the current displayed position of an axis corresponds to
its actual position on the machine when you reference an axis. Your
confirmation is the precondition for the availability of other Safety
Integrated functions.
You can only give your user agreement for an axis after it has
approached the reference point.
The displayed axis position always refers to the machine coordinate
system (MCS = machine).
User agreement with Safety Integrated is only possible with a
software option.
For more information on user agreement, please refer to:
References: /FBSI/, Description of Functions SINUMERIK Safety
Integrated
Jog
 Select "Machine Manual" mode.
Ref Point
 Press the "Ref Point" key on the machine control panel.
X
...
 Select the axis to be traversed.
+
 Press the "+" or "-" key.
The selected axis moves to the reference point and stops. The
coordinate of the reference point is displayed. The axis is marked
.
User
agreement
 Press the "User agreement" softkey.
The "User agreement" window opens.
It shows a list of all machine axes with their current and SI positions.
 Position the cursor in the "Agreement" field for the axis in
question.
- or -
 Give your agreement by pressing the "Alternat." softkey or the
"Select" key.
The selected axis is marked with a cross meaning "safely referenced"
in the "Agreement" column.
Pressing the "toggle keys" again removes your agreement.
