Siemens SINUMERIK 840D Operation/Programming

8
Alarms and Messages 10.04
8.4
V
ersion dis
p
la
y
8
 Siemens AG, 2004. All rights reserved
8-416 SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition
GUD +
or
GUD –
 You can press the "GUD +" and "GUD -" softkeys to display the
global and channel-specific user data from GUD 1 to GUD 9.
Searching for user data
Search
 Press the "Search" softkey.
 Enter the text string that you want to locate.
You can search for any character string.
 Press the "Accept" softkey.
The user data is displayed.
Find next
 Press the "Find next" softkey to continue the search, as
necessary.
The next user data that contains the search string is displayed.
8.4 Version display
You can read the version of the ShopMill-PLC on the ShopMill boot
screen.
The ShopMill and NCU versions are given in the CNC-ISO operator
interface.
 Switch to the CNC ISO operator interface.
Diagnosis
Service
display
 Press the "Diagnosis" and "Service displays" softkeys.
Version
NCU
version
 Press the "Version" and "NCU version" softkeys.
The NCU version is displayed at the top of the window that appears:
xx.yy.zz 810D or 840D
HMI
version
 Press the "HMI version" softkey.
You can read the ShopMill version in the list that is displayed:
PCU 50: ShopMill............ V xx.yy.zz
PCU 20: cmm.dll............. V xx.yy.zz

