Siemens SINUMERIK 840D Operation/Programming

3
Programming with ShopMill 10.04
3.10 Miscellaneous functions
3
 Siemens AG, 2004. All rights reserved
3-298 SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition
Call subroutine
"Tasche_b"
Subroutine call
3.10.2 Repeating program blocks
If certain steps in the machining of a workpiece have to be executed
more than once, it is only necessary to program these steps once.
ShopMill offers a function for repeating program blocks.
You must mark the program blocks that you want to repeat with a start
and end marker. You can then call these program blocks up to 9999
times again within a program. The markers must be unique, i.e. they
must have different names.
You can also set markers and repeats after creating the program, but
not within chained program blocks.
